Superfine Air Classifier Mill is widely used to crush materials with certain viscosity, moisture, and grease, Especially suitable for grinding food materials such as rice, sugar, grains and etc. It has the properties of wind selection, having no sieve or net, and an even granularity of the comminuted material. The production process going on continuously, the machine can undertake the grinding of chemicals, foodstuff, medicines, medicament, cosmetics, plastic, dyestuff, resin, mineral, etc, very super fine powder making, The granularity of the product is even and fineness may reach 60-380 mesh.
- Price Term: FOB/CIF/EXW
- Package: Wooden case or according to customer request
- Delivery Time: 25-35 working days
- Transports: LCL/FCL
- Shipment Port: Shanghai Port
- Origin Of Place: Wuxi City
- Warranty: 12 Months
- Introduction
- Specifications
| Model | YDWF-15 | YDWF-30 | YDWF-40 | YDWF-60 | YDWF-80 |
| Production capacity(kg/hr) | 30-150 | 50-600 | 80-600 | 100-1000 | 200-1500 |
| Speed of principle axis(r/min) | 5800 | 3600 | 3200 | 2900 | 2300 |
| Feeding size(cm) | 5-15 | 5-15 | 5-15 | 5-15 | 5-15 |
| Crushing fineness(mesh) | 80-320 | 80-320 | 80-320 | 80-320 | 80-320 |
| Crushing motor | 7.5kw | 18.5kw | 30kw | 45kw | 55kw |
| Blower | 5.5kw | 18.5kw | 22kw | 22kw | 30kw |
| Grading motor | 1.5kw | 4kw | 5.5kw | 5.5kw | 7.5kw |
| Feeding motor | 0.55kw | 0.75kw | 0.75kw | 0.75kw | 0.75kw |
| discharge motor | 0.75kw | 0.75kw | 0.75kw | 1.1kw | 1.5kw |
| Overall dimension(mm) | 4500×1600×2600 | 6200×1900×3300 | 6500×2100×3300 | 7500×2300×3900 | 8000×2600×4300 |
Hot-selling Equipments For Your Powder Processing Task
Super Fine Air Classifier Mill For Your Powder Handling Task:
It is made up of three parts: the main machine, auxiliary machine, and electric control box. The raw material is delivered to the grinding chamber via hopper by the spiral feeder and is cut and sheared by the high-speed cutters, then the material is moved into the cyclone separator and pulse dust catcher by the negative pressure sucking method. the discharge material meets the product request fineness, by adjusting the classifying wheel speed to get different fineness products, the oversized powder is continued to grinding.
Designed according to GMP standard and wholly made of stainless steel, equipped with a cyclone separator and pulse collector, so there is no powder flying during production. The dust collecting bag can effectively collect the fine powder in the air current so as to meet the requirements for cleanness and environmental protection in waste gas discharge, also can improve the utilization rate of material and reduce the cost of the enterprise, thus reaching the international advanced level.
The benefits of Yinda superfine air classifier mill:
● The main grinding parts are made of high-grade alloy tool steel so that the service life or change cycle of the wear parts is greatly lengthened.
● High-speed precision bearings imported from abroad are adopted for the bearing system so that the whole machine runs smoothly with little vibration and noise.
● The pipes are of quick-detachment construction, making detachment and cleaning quick and convenient.
● Yinda superfine air classifier mill is no need a sieve or screen mesh in the crushing chamber when working, changing powder size by changing speed by inverter.
● Inner temperature is reduced by airflow, and the grinding chamber is used as a water cooling jacket for cooling, which is suitable for heat-sensitive materials.
● Air cooling devices can be equipped to keep temperature remains normal, so the material color and nature won’t change.
Details of Superfine Air Classifier Mill:
It is made up of the main chamber, cyclone discharge, dust collector, blower, and control box.
Cyclone Discharge Valve:
●Cyclone can separate dust from powder(granules).
●The rotary valve makes powder discharge speed even.
●The rotary valve is also made of stainless steel and based on the GMP standard.
●Quick-detachable Construction to Make quick and convenient for clean and installation.
Dust Collector System:
●Dust is collected inside the dust collecting box.
●Inside the box, there are many dust collecting bags, the number of dust boxes is precisely calculated according to the filter area. and the bag frames are also made of stainless steel and can be disassembled easily.
●With pulse-jet cleaning, dust can be filtered and collected very conveniently.
Eu Brand components guarantee quality performance and minimize broken-down time.
