Turmeric Grinding Machine can feed directly with big size materials and grind powder at 20-120mesh. It can crush spice and oily material, whose oil content is less than 25%, and it is also suitable for Chinese herb, roots materials with high fiber content. The crushing size is controlled by screen, and continuous production can be achieved under normal temperature.
Turmeric Grinding Machine is made up of hammer mill, cyclone discharge, dust collector, blower, and control box. Since it features a simple structure, firm, and stable operation and good crushing effect, the comminuted material can be discharged directly from the grinding chamber of the host machine and the desired granule size can be obtained by installing screens with different apertures.
Herbal grinder machine designed according to GMP standard and wholly made of stainless steel, the inner surface of the enclosure becomes smooth through processing, thus changing the powder residual phenomenon due to the coarse inner surface of the previous models.
- Introductions
- Specifications
| Model | YDGS-400 | YDGS-600 | STGS-800 | YDGS-1000 |
| Moto power(kW) | 22 | 37 | 45 | 55 |
| Production capacity(kg/hr) | 100-1000 | 300-1500 | 600-2000 | 1000-3000 |
| Spindle speed(r/min) | 4000 | 4000 | 4000 | 4000 |
| Feeding size(mm) | ≤ 20 | ≤20 | ≤ 20 | ≤ 20 |
| Crushing fineness(mesh) | 20-120mesh | 20-120mesh | 20-120mesh | 20 -120mesh |
| Overall size(L*W*H)mm | 5400*1300*2700 | 6800*1300*2700 | 7800*1800*3200 | 8800*2000*3000 |
