CH50L U Trough Mixer

This U trough mixer is designed for mixing powdered and pasty materials, which enables the main and auxiliary materials to be mixed evenly. It adopts Stainless steel and have a Z-shape agitator in the tank and achieve even mixing effect.

  • Price Term: FOB/CIF/EXW
  • Package: Wooden case or according to customer request
  • Delivery Time: 25-35 working days
  • Transports: LCL/FCL
  • Shipment Port: Shanghai Port
  • Warranty: 12 moths
  • Equipment Advantages: easy installation, fast mixing speed, high mixing uniformity, convenient cleaning, tailored service.
  • Equipment Volume: 50L
  • Batch Weight: 25KG-30KG (specific gravity standard is 1)
  • Mixing time: 3-10 minutes (special materials are determined by customers)
  • Power Supply: 1.5KW
  • Equipment material: SS304, 316L, Carbon steel, etc.
  • Applicable materials: loose dry and wet powder and crystal particles with a specific gravity of 0.1-1.4, especially for rapid mixing in the same batch.
Model
Total volume (L)
Shaft speed (r/min)
Motor (kw)
Discharge motor(kw)
Overall dimension(mm)
weight(kg)
YDCH50
50
24
1.1
0.75
980×425×820
220
YDCH100
100
24
2.2
0.75
1280×440×900
350
YDCH150
150
24
3
0.75
1590×660×1075
500
YDCH200
200
24
4
0.75
1590×660×1125
600
YDCH300
300
24
5.5
1.1
1890×700×1235
750
YDCH400
400
24
5.5
1.1
2140×705×1265
1000
YDCH500
500
22
7.5
1.5
2435×900×1385
1350

U Trough Mixer– The Perfect FAQ Guide

U Trough Mixer is a horizontal shaft mixer used to grind powdered and light pasty materials. It is a very popular equipment primarily used in pharmaceutical and chemical industries due to its capacity to handle a wide range of powders.

It is used to grind a wide range of materials, including food ingredients, ceramics, animal feeds, spices, sugars, disinfectants, agriculture, vitamins and minerals.  U Trough Mixer consists of mixer, speed reducer, motor device, and electric control box and equipment lubrication of machine parts.

If you are searching for a durable and high-quality U Trough Mixer, Yinda machinery is here to assist you in giving the right solution to your problem. It has a U shaped vessel with a rotating agitator. It has a relatively simple structure and is easy to operate. It is a perfect and robust mixing solution for powders and other materials. There are various sizes and capabilities of U Trough Mixer available from few meters to several cubic meters. We can help you in finding the best mixer to fulfil your company’s needs.

Features of U Trough Mixer

The U Trough Mixer incorporates a wide range of features and qualities that provide excellent mixing and easier maintenance.

  • It has spiral type blades that make mixing very efficient.
  • It is made of stainless steel material and has a robust structure. The structure is made in compliance with the GMP standard.
  • Material is discharged using a motor device which decreases labour intensity. There is a manual and automatic option in mixing according to the preference of the customer.
  • It has easier installation and convenient cleaning because of the increased space between shaft seals and bearings.
  • It has a short mixing time combined with gentle mixing and low energy consumption.
  • The high efficiency of U Trough Mixer makes sure that the ingredients are mixed homogenously.

Choosing the suitable U Trough Mixer for your company’s requirements is not an easy task. Our team of professionals can assist you and make sure that the equipment you purchase fulfils the requirements.

Structure of U Trough Mixer

U Trough Mixer consists of an Interrupted spiral blade and a Contra flow blade or back paddle blade. These blades are perfect for powders, pastes and liquid mixes. They gave a gentle mix with minimum power consumption, less maintenance and shorter cleaning time. They are highly efficient and easy to clean with clean arm attachments. The spiral blade mixer offers more quick and improved mixing. You can choose from the choices of blade designs according to your requirements. The construction of all parts of U Trough Mixer is made of stainless steel. It can be designed and manufactured as per the requirements of the customers.



Working Principle of U Trough Mixer

U Trough Mixer is simple yet effective mixing equipment. It works on two primary principles; convective mixing and diffusion. When it comes to large-sized materials, convective mixing is used. Diffusion mixing takes place when all individual particles move in one particular direction. There is a horizontal mixing blender from where the material is put by using feeding devices. The U Trough Mixer provides the perfect homogenous mixing of the materials.

If you are looking for the U trough mixer for your production, we at Yinda machinery are here to provide you with full assistance.

Yinda is the best choice for a U trough mixer and offers the best solution for your project’s and company’s requirements. Call us at +86-139-1419-2807 or email us at dennie@yindamachinery.com
