V500-V2000L Bin Blender
V dry powder blender is suitable for use in the pharmaceuticals, chemical and food industries for mixing powder or granular materials.
The cylindrical structure is the distinguishing feature and the mixing ability is well-proportioned and efficient with no blind spots in the cylinders and no accumulation of materials.
V type dry powder blender machine is straight forward and it is easy to operate with a surface that is easy to clean in a highly finished stainless steel.
- Price Term: FOB/CIF/EXW
- Package: Wooden case or according to customer request
- Delivery Time: 25-35 working days
- Transports: LCL/FCL
- Shipping Port: Shanghai Port
- Warranty: 12 moths
- Specifications
- Specifications
- Equipment advantages: easy installation, fast mixing speed, high mixing uniformity, convenient cleaning, tailored service.
- Mixing amount each time: 40KG-800 KG (specific gravity standard is 1)
- Mixing time: 6-10 minutes (special materials are determined by customers)
- Drive power: 3KW-5.5 KW
- Equipment material: SS304, 316L, Carton steel etc
- Applicable materials: loose dry powder and crystal particles with a specific gravity of 0.1-2, especially for rapid mixing in the same batch.
Model
| YDV-1000 | YDV-1500 | YDV-2000 |
| Working Volume (m3) | 400 | 600 | 800 |
| Mixing time(min) | 6-10 | 12-18 | 12-18 |
Barrel speed (r/min)
| 12 | 12 | 12 |
| Motor power(kw) | 4 | 5.5
| 7.5
|
| Forced agitator(kw) | 3 | 4 | 5.5 |
| Overall size(mm) | 3070*1240*2490 | 3900*1440*3100 | 3900*1440*3100 |
| Weight (kg) | 860 | 2040 | 2040 |
